The ACL PCL Instruments Set brings together a comprehensive range of orthopedic instruments to support anterior cruciate ligament (ACL) and posterior cruciate ligament (PCL) reconstruction procedures within knee arthroscopy workflows. Specifically, the set covers aiming and guide functions, arthroscopic probing, graft preparation, tunnel drilling, depth measurement, and finishing — all organized into a single instrument case for structured storage and handling.
This set is intended for use by qualified orthopedic and arthroscopic surgical teams in appropriate professional surgical environments.
Instruments Included
| Instrument | Size / Specification | Qty. |
|---|---|---|
| Femoral Aimer | 7mm Open | 1 |
| Femoral Aimer | 6mm Open | 1 |
| Femoral Aimer | 5mm Open | 1 |
| Guider Clamp | — | 1 |
| Arthroscopic Probe | 30° | 1 |
| Arthroscopic Probe | 45° | 1 |
| Arthroscopic Probe | 90° | 1 |
| PCL Protector | — | 1 |
| Tendon Stripper (Open) | 7mm Open | 1 |
| Tendon Stripper (Closed) | 7mm Closed | 1 |
| Depth Scale | 0–120mm | 1 |
| Main Jig | — | 1 |
| ACL Elbow Aimer | — | 1 |
| PCL Femoral Aimer | — | 1 |
| PCL Tibia Aimer | — | 1 |
| Tube | — | 1 |
| Graft Passing Pin | Ø2.4 × 320mm | 1 |
| Graft Passing Pin | Ø2.4 × 420mm | 1 |
| Depth for ACL/PCL | 6mm–12mm | 1 |
| Tunnel Plug | 8–9mm | 1 |
| Tunnel Plug | 7–8mm | 1 |
| Handle | — | 1 |
| Tunnel Plug | 7mm | 1 |
| Tunnel Plug | 8mm | 1 |
| Tunnel Plug | 9mm | 1 |
| Cannulated Tibia Reamer | Ø6mm × 175mm | 1 |
| Cannulated Tibia Reamer | Ø7mm × 175mm | 1 |
| Cannulated Tibia Reamer | Ø8mm × 175mm | 1 |
| Cannulated Tibia Reamer | Ø9mm × 175mm | 1 |
| Cannulated Tibia Reamer | Ø10mm × 175mm | 1 |
| Cannulated Tibia Reamer | Ø11mm × 175mm | 1 |
| Cannulated Femur Reamer | Ø4.5mm × 175mm | 1 |
| Cannulated Femur Reamer | Ø6mm × 175mm | 1 |
| Cannulated Femur Reamer | Ø7mm × 175mm | 1 |
| Cannulated Femur Reamer | Ø8mm × 175mm | 1 |
| Cannulated Femur Reamer | Ø9mm × 175mm | 1 |
| Cannulated Femur Reamer | Ø10mm × 175mm | 1 |
| Cannulated Femur Reamer | Ø11mm × 175mm | 1 |
| Block Screwdriver | — | 1 |
| Straight Rasp | — | 1 |
| Convex Rasp | — | 1 |
| Graft Prep Station | — | 6 |
| Instrument Case | — | 1 |
| Total | 48 |
ACL PCL Reconstruction Set
ACL and PCL reconstruction procedures share a number of common workflow stages, yet each involves distinct instrument requirements. ACL reconstruction requires accurate femoral and tibial tunnel positioning, graft harvest, graft preparation, graft passage, and tunnel finishing. PCL reconstruction covers comparable stages but with anatomically different approach angles, guide positions, and aimer configurations.
This ACL PCL Reconstruction Set consolidates instruments for both procedures into a single organized collection. It includes aiming guides for femoral and tibial positioning, arthroscopic probes for intra-articular assessment, tendon strippers for graft preparation, cannulated reamers in multiple diameters for tunnel creation, graft passing pins, depth measurement instruments, tunnel plugs in several sizes, rasps for surface finishing, and a dedicated instrument case.
For surgical teams who need to support both ACL and PCL reconstruction workflows, this consolidated configuration reduces the need to source instruments from multiple separate sets.
ACL PCL Reconstruction Instrument Set
The instruments within this set fall into logical functional groups that correspond to different stages of a reconstruction workflow.
Aiming and Guide Instruments
Aiming instruments help establish the trajectory for guide pins and reamers during tunnel preparation. Accurate placement of these instruments directly determines where bone tunnels are created in relation to the anatomical ligament insertion sites.
Femoral Aimers (5mm, 6mm, 7mm Open): Three open femoral aimers — in 5mm, 6mm, and 7mm configurations — direct a guide pin toward the intended femoral tunnel position. Different offset sizes allow the surgical team to select the aimer that matches the planned tunnel geometry.
ACL Elbow Aimer: This aimer is shaped for ACL femoral tunnel positioning and engages within the intercondylar notch area at the appropriate anatomical location.
PCL Femoral Aimer: A dedicated aimer for PCL femoral tunnel positioning, where the approach angle and notch geometry differ from ACL femoral tunnel preparation.
PCL Tibia Aimer: Configured for tibial tunnel preparation in PCL reconstruction, this instrument helps control the directional path of the guide pin near the posterior tibial cortex.
Guider Clamp: This clamping instrument stabilizes and secures guide components during the aiming and drilling process.
Main Jig: The central jig body provides the structural frame to which aiming arms and tubes attach, enabling coordinated guide wire positioning.
Arthroscopic Instruments
Arthroscopic Probes (30°, 45°, 90°): Three arthroscopic probes at different angles allow intra-articular inspection and tissue assessment. Furthermore, angled probes help the surgeon evaluate structures within the knee joint from multiple perspectives through the arthroscopic portals.
PCL Protector: During PCL tunnel preparation, this instrument protects surrounding anatomical structures — particularly when the surgical team works in proximity to the posterior aspect of the knee.
Graft Preparation and Passage
Open Tendon Stripper (7mm): This instrument prepares soft tissue grafts, specifically for harvesting and stripping tendon material from surrounding tissue during graft collection.
Closed Tendon Stripper (7mm): The closed-end variant offers an alternative configuration for tendon stripping, depending on the graft type and surgical preference.
Graft Passing Pins (Ø2.4 × 320mm and Ø2.4 × 420mm): Two graft passing pins in different lengths thread the prepared graft through the bone tunnels after tunnel creation. The two available lengths — 320mm and 420mm — accommodate different tunnel depth and approach requirements.
Graft Prep Station (×6): Six graft preparation stations help tension and prepare the graft prior to implantation, sizing and conditioning the graft tissue before passage.
Handle and Tube: These components work with associated instruments in the jig and guide assembly for directing instruments or guide wires.
Depth and Tunnel Preparation
Depth Scale (0–120mm): This calibrated instrument covers a 0–120mm range and measures tunnel depth and graft length during the procedure.
Depth for ACL/PCL (6mm–12mm): This instrument provides depth reference specific to ACL and PCL tunnel preparation within the 6mm–12mm dimensional range.
Tunnel Plugs (7mm, 8mm, 9mm, 7–8mm, 8–9mm): Five tunnel plugs in varying sizes temporarily manage the prepared bone tunnels during the procedure. The range of sizes — including both fixed and stepped configurations — covers the tunnel diameters that reamers in this set can produce.
Cannulated Tibia Reamers (Ø6–11mm × 175mm): Six cannulated tibial reamers in 1mm incremental diameter steps — from 6mm to 11mm — each at a 175mm working length, pass over a guide pin to create the tibial bone tunnel at the appropriate diameter.
Cannulated Femur Reamers (Ø4.5mm, Ø6–11mm × 175mm): Seven cannulated femoral reamers start at Ø4.5mm and continue from Ø6mm through Ø11mm in 1mm steps, all at 175mm. The 4.5mm size supports initial tunnel preparation steps where a smaller starting diameter is appropriate.
Finishing and Supporting Instruments
Block Screwdriver: This instrument works with block or interference fixation components.
Straight Rasp: The straight-profile rasp prepares or finishes surfaces within the bone tunnel or on adjacent bone.
Convex Rasp: The convex profile conforms to curved bone surfaces, making it suitable for finishing tasks in areas where a straight rasp cannot lie flat.
Instrument Case: A dedicated case organizes and stores all instruments within the set.
ACL/PCL Surgical Instruments Set
A key practical consideration in any reconstruction instrument collection is how individual instruments work together as a coordinated system. In this set, aiming guides, reamers, depth measurement tools, graft preparation components, and finishing instruments form a logical sequence that follows the stages of ACL or PCL reconstruction.
For example, the three femoral aimer sizes (5mm, 6mm, 7mm) provide flexibility for different tunnel positions and backwall preferences. Similarly, the tiered reamer diameters for both the tibia and femur allow the surgical team to match the tunnel size to the prepared graft diameter. Additionally, because the set includes both ACL-specific and PCL-specific aiming instruments, teams working across both procedures do not need to maintain entirely separate instrument collections.
However, the exact instruments a surgeon selects for any given procedure will depend on the technique, the patient’s anatomy, the graft type, and the clinical requirements of the case. Not every instrument in this set will apply to every procedure.
ACL/PCL Reconstruction Knee Arthroscopy Instruments Kit
This set covers multiple instrument stages relevant to ACL and PCL reconstruction within an arthroscopic surgical context. Key dimensional specifications include:
- Femoral aimers in three open sizes: 5mm, 6mm, and 7mm
- Graft passing pins in two lengths: 320mm and 420mm, both at Ø2.4mm diameter
- Depth scale range: 0–120mm
- Depth instrument for ACL/PCL: 6mm–12mm
- Cannulated tibial reamers: Ø6mm, Ø7mm, Ø8mm, Ø9mm, Ø10mm, Ø11mm — all at 175mm
- Cannulated femoral reamers: Ø4.5mm, Ø6mm, Ø7mm, Ø8mm, Ø9mm, Ø10mm, Ø11mm — all at 175mm
- Tunnel plugs: 7mm, 8mm, 9mm (individual), plus 7–8mm and 8–9mm stepped sizes
- Tendon strippers: open 7mm and closed 7mm configurations
- Arthroscopic probes: 30°, 45°, and 90° angles
Together, this dimensional range gives surgical teams flexibility across the tunnel sizes commonly associated with soft tissue graft reconstruction.
Material and Construction
Premium German Stainless Steel and Titanium
This ACL PCL Instruments Set is available in two material configurations: premium German stainless steel and titanium. German stainless steel carries a long-standing reputation in professional surgical instrument manufacturing for its structural integrity, working hardness, and resistance to corrosion under standard instrument processing conditions. Titanium, by contrast, offers a lighter alternative while maintaining high strength — a combination that makes it a preferred option in some surgical instrument applications.
The available material configuration depends on the specific product order. The material information above applies at the set level as the manufacturer supplies it; individual component-level material specifications are not confirmed in the product data.
Product Features
- Combined ACL and PCL instrument configuration in a single organized set
- Three femoral aimer sizes (5mm, 6mm, 7mm) for tunnel position flexibility
- Dedicated ACL Elbow Aimer, PCL Femoral Aimer, and PCL Tibia Aimer
- Three arthroscopic probe angles (30°, 45°, 90°) for intra-articular assessment
- PCL Protector for posterior structure management during PCL tunnel preparation
- Six cannulated tibial reamers (Ø6–11mm × 175mm) in 1mm diameter steps
- Seven cannulated femoral reamers (Ø4.5mm, Ø6–11mm × 175mm) including a 4.5mm starter size
- Graft passing pins in two lengths (320mm and 420mm) at Ø2.4mm
- Five tunnel plugs covering 7mm, 8mm, 9mm, 7–8mm, and 8–9mm
- Open and closed tendon strippers (both 7mm)
- Depth scale covering 0–120mm and ACL/PCL depth instrument (6–12mm range)
- Six Graft Prep Stations for graft conditioning prior to passage
- Straight and convex rasps for bone surface finishing
- Supplied with a dedicated instrument case for organized storage
- Available in premium German stainless steel and titanium configurations
Professional Application
This instrument set is intended for use by qualified healthcare professionals in appropriate orthopedic and arthroscopic surgical environments. The instruments within the set support workflows associated with ACL and PCL reconstruction procedures and related knee arthroscopy tasks — including guide wire positioning, tunnel preparation, graft handling, and tunnel finishing.
Ultimately, the qualified surgical team selects specific instruments from this set for any given procedure, based on the surgeon’s technique, the patient’s anatomy, and the clinical requirements of the case.
Frequently Asked Questions
What is an ACL PCL Instruments Set?
An ACL PCL Instruments Set is an organized collection of orthopedic surgical instruments assembled to support anterior cruciate ligament (ACL) and posterior cruciate ligament (PCL) reconstruction procedures. Typically, the set includes aiming guides, reamers, probes, graft preparation tools, depth instruments, tunnel plugs, and related accessories that surgical teams use across the stages of ligament reconstruction within a knee arthroscopy context.
What instruments are included in the ACL PCL Instruments Set?
This set includes femoral aimers (5mm, 6mm, 7mm), an ACL Elbow Aimer, a PCL Femoral Aimer, a PCL Tibia Aimer, a Guider Clamp, a Main Jig, arthroscopic probes at 30°, 45°, and 90°, a PCL Protector, open and closed tendon strippers (7mm), graft passing pins (Ø2.4 × 320mm and Ø2.4 × 420mm), six Graft Prep Stations, a depth scale (0–120mm), a depth instrument for ACL/PCL (6–12mm), five tunnel plugs in various sizes, six cannulated tibial reamers (Ø6–11mm × 175mm), seven cannulated femoral reamers (Ø4.5–11mm × 175mm), a block screwdriver, straight and convex rasps, a handle, a tube, and an instrument case.
What is the difference between ACL and PCL reconstruction instruments?
Both ACL and PCL reconstruction involve femoral and tibial tunnel preparation, graft passage, and fixation — however, the anatomical approach angles and target positions differ between the two procedures. PCL reconstruction, for example, requires working toward the posterior tibial cortex, where proximity to neurovascular structures demands careful directional control. That is why this set includes dedicated PCL-specific instruments — the PCL Femoral Aimer, PCL Tibia Aimer, and PCL Protector — alongside the ACL-specific components, rather than relying on a shared set of guides for both.
What sizes of reamers are included?
Six cannulated tibial reamers cover Ø6mm through Ø11mm in 1mm steps, all at 175mm length. Additionally, seven cannulated femoral reamers cover Ø4.5mm and Ø6mm through Ø11mm, also at 175mm. Together, this tiered range allows the surgical team to match the reamer diameter to the planned graft size and tunnel specification.
What sizes of femoral aimers are available?
The set includes three open femoral aimers — 5mm, 6mm, and 7mm. In addition, a dedicated ACL Elbow Aimer and a PCL Femoral Aimer address the specific anatomical requirements of each ligament’s femoral tunnel approach.
Are ACL PCL instruments available in German stainless steel and titanium?
Yes. This set is available in both premium German stainless steel and titanium configurations. The specific material for a given order depends on the product configuration the customer selects. Both materials have established use in professional surgical instrument manufacturing.
Is the instrument case included?
Yes. One instrument case is part of the set, providing organized storage and handling for all instruments.
Are the instruments suitable for knee arthroscopy?
The set includes components associated with arthroscopic approaches to ACL and PCL reconstruction — including angled arthroscopic probes and instruments sized for arthroscopic portal access. However, whether these instruments suit a specific surgical technique and patient case is a determination the qualified surgical team must make based on their clinical judgment.
